Cordless TruTool S 160 Metal Shear

Our Price $1,050.00

The rechargeable TruTool S160 metal shear is continuously powered by a strong electrical motor allowing for speedy, precise, clean and burr-free cuts in straight and curved lines in plates and formed steel. TRUMPF combines a job proven design and a sturdy shear head to deliver unsurpassed maneuverability and versatility while maintaining excellent visibility of the cutting line when shearing to scribing.

SKU: 1886630 Category:

The Rechargeable, Cordless TruTool S 160 Metal Shearing Tool For Sale

With the TruTool S 160 10.8 V battery machine, you are perfectly equipped for processing sheet metal up to 0,63 inch thick in mild steel. Here, the interference contours are almost non-existent. The battery machine enables you to work comfortably and with little effort. The 10.8 V battery provides an above-average runtime. It cuts approximately 33 feet in 57,000 mild steel at a sheet thickness of 0.03 inches. You can even double this service life with the 4 Ah battery.

If you often process thin sheet up to 1.6 mm, and want a model at a good price, you should choose the TruTool S 160. The compact shear is attractive for its high curve mobility and chip-free cuts. This tool responds comprehensively to your requirement for flexibility. The reversible cutting blades can be used on all four sides. This is advantageous for the cut-meter costs.

Particularly suitable for thin sheet work

  • Easy to exchange, 4-sided, cutting blades
  • Ideal for thin metal applications
  • Excellent price / performance ratio
  • Machine available as electric-version

Applications

  • Plumbers
  • Electrical fitters
  • Sanitary / Heating / Ventilation works
  • Container construction
  • Elevators
  • General sheet metal processing operations
  • Coil-application



DETAILED SPECIFICATIONS

Maximum sheet thicknesses


Maximum sheet thickness, steel up to 400 N/mm²

1.6 mm

Maximum sheet thickness, steel up to 600 N/mm²

1.2 mm

Maximum sheet thickness, aluminum up to 250 N/mm²

2 mm

Radii


Smallest radius

15 mm

General


Working Speed

5 m/min – 9 m/min

Idle run stroke rate

4’300 RPM

Starting hole diameter

27 mm

Voltage

10.8 V

Weight


Weight (with 2 Ah rechargable battery)

1.6 kg

Weight (with 4 Ah rechargable battery)

1.8 kg

SERVICE MANUALS

FABTECH SOLUTIONS is a proud distributor of Trumpf Power Tools. Our Service Department can assist with finding the right tool for the job. Ensuring high quality equipment, training and service resources is an essential component for prolonging the life and effectiveness of your sheet metal fabrication power tools and machinery.

For your convenience, there are instruction and service manuals for your Trumpf TruTools included below. These manuals have been prepared for operators and maintenance personnel. It is important that all persons responsible for the care and operation of this equipment fully understand the information presented in this material. Manuals are shown for reference purposes only; please contact our Service Department with any questions or concerns.

TRUMPF Cutting Shears
