Cordless TruTool PN 201 Profile Nibbler

Our Price $1,530.00

The Battery Operated TRUMPF TruTool PN 201 Profile Nibbler is designed for durable operation and has a long lasting runtime. The 4AH rechargeable battery can cut up to 54 meters of mild steel with a sheet thickness of 1mm. Overall, the PN 201 can cut stainless steel and sheet metal up to 2mm thick, and is used for processing profile depths of up to 6.37 in. Also well-suited to C-L-U profiles.

SKU: 2081667 Category:

The Cordless, Rechargeable TruTool PN 201 Profile Nibbler (Li-ion Battery) For Sale

The TruTool PN 201 battery operated Profile Nibbler can cut sheet thicknesses in mild steel up to 2 mm, even in the case of doubled sheets. The PN 201 comes with a long tool and is particularly well-suited for deep trapezoidal sheets of up to 162 mm. The tool can be rotated 360° on the spot. The cutting direction, punch, and die carrier can be changed quickly, without the need for tools. With the 4 Ah rechargeable battery you can cut up to 54 meters in mild steel with a sheet thickness of 1 mm.

Strong profile nibbler: cuts sheet thicknesses up to 2 mm in mild steel

  • Powerful machine
  • Especially impressive when cutting double sheets
  • For highest curve maneuverability
  • No sparks
  • Quick&Easy: tool-free cutting-, punch- and tool change
  • One machine – three tools
  • Machine available as electric-version

Applications

  • Roof and fasade construction
  • Ventilation works and climate control technology
  • Plumbers
  • Encasings and covers

DETAILED SPECIFICATIONS

Maximum sheet thicknesses


Maximum sheet thickness, steel up to 400 N/mm²

2 mm

Maximum sheet thickness, steel up to 600 N/mm²

1.5 mm

Maximum sheet thickness, steel up to 800 N/mm²

1 mm

Maximum sheet thickness, aluminum up to 250 N/mm²

3 mm

Radii


Smallest radius

50 mm

General


Working Speed

1.6 m/min

Idle run stroke rate

1200 1/min

Starting hole diameter

24 mm

Voltage

18 V

Weight


Weight (with 2 Ah rechargable battery)

2.2 kg

Weight (with 4 Ah rechargable battery)

2.5 kg

SERVICE MANUALS

FABTECH SOLUTIONS is a proud distributor of Trumpf Power Tools. Our Service Department can assist with finding the right tool for the job. Ensuring high quality equipment, training and service resources is an essential component for prolonging the life and effectiveness of your sheet metal fabrication power tools and machinery.

For your convenience, there are instruction and service manuals for your Trumpf TruTools included below. These manuals have been prepared for operators and maintenance personnel. It is important that all persons responsible for the care and operation of this equipment fully understand the information presented in this material. Manuals are shown for reference purposes only; please contact our Service Department with any questions or concerns.
