TruTool TSC 100 Slat Cleaner

FREE SHIPPING!!!

Our Price $6,500.00

TRUMPF TruTool TSC 100 Laser Slat Cleaner makes it possible for a single person to clean the slats of your plasma laser tables. An ergonomic design allows for comfortable use while the slat cleaner automatically adjusts to varying slag thickness. The TSC 100 improves the quality and productivity of sheet metal processing while eliminating the need of using a hammer or other hack to remove the steel slag.

SKU: 1893361 Category:

Product Details

Common Accessories…

The TRUMPF TruTool TSC 100 Slat Cleaner For Sale Today

The TRUMPF TruTool TSC 100 slat cleaner is an essential tool for every sheet metal processor, ergonomically designed for single person operation this tool will restore your plasma table to proper working condition. This is an essential TruTool for ever sheet metal and metal working shop. The slat cleaner can be used to remove slag in specific work areas or entire surfaces. Heavily soiled slats can be cleaned easily and efficiently, even stainless steel slag can be reliably removed in one simple procedure.

The TruTool TSC 100 slat cleaner removes the accumulated slag on plasma tables that comes from production use. The slat cleaner automatically adapts to different slag thicknesses. This laser slat cleaner is designed to thoroughly remove all slag debris from crevices and side surfaces in one single process. It is thorough and efficient, and will extend the life of your equipment.

TruTool TSC 100 can be operated by just one person and the machine is very easy to handle. On a flatbed CNC plasma laser machine with a pallet changer, cleaning takes place while production is running. You don’t even have to remove the slats.

Trouble-free repeated slat cleaning

  • Suited for the most diverse materials: stainless steel, mild steel and aluminium
  • TruTool TSC 100 can be used on virtually all CO2 and SSL 2D laser cutting machines
  • Can be used on laser machines with up to 7 kW of laser power
  • Increases the life of flatbed laser slats by up to 75%
  • Cleaning takes place while operation is running (on flatbed laser machines with a pallet changer)
  • Adapts automatically to different slag thicknesses

DETAILED SPECIFICATIONS

TRUMPF Slat Cleaner, TruTool TSC 100
Support slats thickness2 mm – 3.9 mm
Max. slag thickness25 mm
Min. spacing between support slats33.5 mm
Working speed4 m/min – 8m/min
Rated input power1400 W
Weight (without cable)18 kg
Accessories included
Cleaning tool no. 33 – 3.9 mmintegrated
Handle complete0369003
Transport rollersincluded
Hexagon head screw4 mmincluded
Hexagon head screw6 mm1640682
Additional accessories
Cleaning tool No. 2110 – 120 VSet of 2 1644868
Cleaning tool No. 32 – 2.9 mm0349350
Carbon brush (set of 2)3 – 3.9 mmSet of 2 1644867
Carbon brush (set of 2)220 – 230 V0349442

SERVICE MANUALS

FABTECH SOLUTIONS is a proud distributor of TRUMPF Power Tools. Our Service Department can assist with finding the right tool for the job. Ensuring high quality equipment, training and service resources is an essential component for prolonging the life and effectiveness of your sheet metal fabrication power tools and machinery.

Explore TRUMPF Replacement Parts and Repair Services

For your convenience, there are instruction and service manuals for your TRUMPF TruTools included below. These manuals have been prepared for operators and maintenance personnel. It is important that all persons responsible for the care and operation of this equipment fully understand the information presented in this material. Manuals are shown for reference purposes only; please contact our Service Department with any questions or concerns.

TRUMPF TruTool Slat Cleaner
