TruTool C 160 Shear with Chip Breaker

Our Price $1,150.00

The rechargeable TRUMPF TruTool C 160 Slitting Shear, with integrated chip clipper for two handed application. The chips are clipped with a three-quarter clockwise turn by means of a lever, you can cut chips at any time and pull the machine out of the workpiece. The gear head comes with Power-Head Technology which allows for battery optimized use.

SKU: 1886684 Category:

The TruTool C 160 Li-ion 10.8 V Cordless Slitting Shear For Sale

The TRUMPF C160 comes with an integrated chip clipper for two-handed operation, is an excellent match for notching work and interior cutouts of up to 1.6 mm in mild steel and 1.2 mm in stainless steel. It enables you to clip chips at any point. The 10.8 V battery provides an above-average runtime. The 2 Ah battery cuts around 70 meters in 400 N/mm2 mild steel at a sheet thickness of 0.8 mm. You can even double this service life with the 4 Ah battery. Many details in the gear head are tailored to the voltage of the battery technology and enable the 10,8 volt battery to produce output that is comparable to a 14,4 volt battery.

The alternative with integrated chip breaker

  • Integrated chip breaker for two-handed operation; ideal for inner contours and notchings
  • Light weight, ergonomic, handy
  • Machine available as electric version as well Li-Ion-battery

Applications

  • Ventilation works and climate control technology (spiral-seam tubes)
  • House-front construction
  • Construction, including separation of C-L-U profiles
  • Plumbers
  • Coil-application

DETAILED SPECIFICATIONS

Maximum sheet thicknesses


Maximum sheet thickness, steel up to 400 N/mm²

1.6 mm

Maximum sheet thickness, steel up to 600 N/mm²

1.2 mm

Maximum sheet thickness, aluminum up to 250 N/mm²

2 mm

Spiral duct steel 400 N/mm²

4 x 0,63 mm

Radii


Smallest radius

90 mm

General


Working Speed

5 m/min – 9 m/min

Idle run stroke rate

4300 RPM

Starting hole diameter

15 mm

Voltage

10.8 V

SERVICE MANUALS

FABTECH SOLUTIONS is a proud distributor of Trumpf Power Tools. Our Service Department can assist with finding the right tool for the job. Ensuring high quality equipment, training and service resources is an essential component for prolonging the life and effectiveness of your sheet metal fabrication power tools and machinery.

For your convenience, there are instruction and service manuals for your Trumpf TruTools included below. These manuals have been prepared for operators and maintenance personnel. It is important that all persons responsible for the care and operation of this equipment fully understand the information presented in this material. Manuals are shown for reference purposes only; please contact our Service Department with any questions or concerns.

TRUMPF Slitting Shears

NEED IMMEDIATE SERVICE?

Our expert team of factory-trained service engineers can discuss machine tool repair options with you today, we can effectively minimize your downtime and keep your manufacturing process running smoothly. Look into one of our maintenance contracts to ensure quality and optimal service for all your machine fabrication needs.
