Cordless TruTool C 200 Shear (Li-ion Battery)

FREE SHIPPING!!!

Our Price $1,350.00

The TRUMPF TruTool C200 is a specialized shear and an ideal addition to a fabrication shop. The rechargeable battery allows for an above average runtime. The 18V battery can separate mild steel sheet thickness of up to 2mm and fold thickness up to 3.6mm; including stainless steel sheets up to 1.5mm.

SKU: 2328823 Category:

Product Details

Common Accessories…

The Rechargeable TruTool C 200 Slitting Shear (Li-ion 18V Battery) For Sale

The Cordless Trumpf C200 Li-ion 18V rechargeable metal shear is particularly well-suited to cutting tasks and features an open cutting head. A chip clipper is not necessary with this model of metal shear. You can achieve an extraordinary amount of power when cutting spiral ducts. The tool set used for spiral ducts, which consists of toothed cutting blades and a robust SC cutter, is capable of fold thicknesses of up to 3.6 mm with mild steel and enables both longitudinal sections and cross-sections.

Trumpf offers six different cutting sets and blades to increase the versatility of this metal slitting shear. The Set Spiro is perfect for cutting spiral ducts and can even cut sheet thicknesses of up to 3.6 mm. The Set HighSpeed enables you to process sheet thicknesses of 1.5 – 2 mm. The focus here is on speed, with a slightly reduced cutting quality. If you are cutting visible edges, we recommend the Set HighQuality for 1.5 – 2 mm or the Set ThinSheet for up to 1.5 mm. Use the Set CR if the focus is on processing stainless steel, and the Set Curves for tight curves and radii from R 45 / L 80.

C200’s Best Features:

  • 3 different cutting blades allow for specialization
  • Open cutting head, without chip clipper, enables the machine to pull easily out of the sheet
  • Power-Head-Technology and brushless motor allows for a 60% longer battery runtime

Cutting Ranges with Li-ion Battery

  • Separate Mild Steel Sheet Thicknesses up to 2mm up to approx 15 meters
  • 2 Ah rechargeable battery cuts in mild steel and sheet thicknesses of 1.5 mm up to approx. 50 meters
  • Fold steel thickness up to 3.6mm
  • Double these runtimes with the 4AH 18V Rechargeable Battery

DETAILED SPECIFICATIONS

TruTool C 200 Li-Ion 18 V
Maximum sheet thicknesses


Spiral duct steel 400 N/mm²

4 x 0,9 / 6 x 0,6 mm

Spiral duct steel 600 N/mm²

4 x 0,6 mm

Radii


Smallest radius

150 mm

General


Working Speed

3 m/min – 10 m/min

Starting hole diameter

8 mm

Voltage

18 V

Weight


Weight (with 2 Ah rechargable battery)

2.3 kg

Weight (with 4 Ah rechargable battery)

2.6 kg

SERVICE MANUALS

FABTECH SOLUTIONS is a proud distributor of Trumpf Power Tools. Our Service Department can assist with finding the right tool for the job. Ensuring high quality equipment, training and service resources is an essential component for prolonging the life and effectiveness of your sheet metal fabrication power tools and machinery.

For your convenience, there are instruction and service manuals for your Trumpf TruTools included below. These manuals have been prepared for operators and maintenance personnel. It is important that all persons responsible for the care and operation of this equipment fully understand the information presented in this material. Manuals are shown for reference purposes only; please contact our Service Department with any questions or concerns.

TRUMPF Slitting Shears
